Name: 1761562001
Brand: Weidmüller
SKU: 1761562001
Price: 2.20000 USD
Availability: InStock

new-10%

1761562001

Manufacturer part number:1761562001

Manufacturer:Weidmüller

Description:1761562001 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1761562001 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2002
Series	Omnimate SL
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	Not Applicable
Type	Header, Male Pins, Shrouded (4 Side)
Color	Black
Number of Rows	1
Gender	Male
Voltage - Rated	300V
Additional Feature	HIGH DENSITY
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.138 3.50mm
Total Number of Contacts	4
Ingress Protection	IP10
Insulation Height	0.293 7.44mm
Current Rating	13A
Termination Style	Solder
Approval Agency	CSA, UR
Insulation Resistance	1MOhm
Voltage	300V
Contact Tail Length	0.059 1.50mm
Number of Levels	1
Current	10A
Number of Poles	4
Contact Mating Finish	Tin
Voltage - IEC	320V
Header Orientation	90°, Right Angle
Current - IEC	15A
Hole Diameter	1.4 mm
Height	7.5mm
Length	15.4mm
Width	11.1mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1761562001 Product Details

1761562001 Overview

There is a mounting type of Through Hole for this device.An orange Bulk case is used to package the product.This product is from the Omnimate SL Series.Also, there's HIGH DENSITY, to name a few.This part is mounted by Through Hole. Operating temperature is set to -50°C~100°C.This part shares lots of benefits with other Header, Male Pins, Shrouded (4 Side) products.
