Name: 1630480000
Brand: Weidmüller
SKU: 1630480000
Price: 0.69000 USD
Availability: InStock

new-10%

1630480000

Manufacturer part number:1630480000

Manufacturer:Weidmüller

Description:1630480000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1630480000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2004
Series	Omnimate SL
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Type	Header, Male Pins, Shrouded (4 Side)
Color	Orange
Number of Rows	1
Voltage - Rated	300V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.197 5.00mm
Total Number of Contacts	2
Insulation Height	0.484 12.30mm
Current Rating	17A
Termination Style	Solder
Approval Agency	CSA, UR
UL Flammability Code	94V-0
Insulation Resistance	1MOhm
Voltage	300V
Contact Tail Length	0.126 3.20mm
Number of Levels	1
Current	10A
Number of Poles	2
Contact Mating Finish	Tin
Current - UL	15A
Voltage - IEC	400V
Header Orientation	135°
Hole Diameter	1.3 mm
Height	12.3mm
Length	12mm
Width	13.1mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1630480000 Product Details

1630480000 Overview

This device's mounting type is Through Hole.It is necessary to use a Bulk case for packaging the product.It is part of the Omnimate SL Series of products.Through Hole represents the mounting point for the part.Device runs in -50°C~100°C operating temperature.This part shares lots of benefits with other Header, Male Pins, Shrouded (4 Side) products.
