Name: 1605130000
Brand: Weidmüller
SKU: 1605130000
Price: 3.57000 USD
Availability: InStock

new-10%

1605130000

Manufacturer part number:1605130000

Manufacturer:Weidmüller

Description:1605130000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1605130000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2008
Series	Omnimate SL
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Type	Header, Male Pins, Shrouded (4 Side)
Color	Orange
Number of Rows	1
Voltage - Rated	300V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.138 3.50mm
Total Number of Contacts	8
Orientation	Right Angle
Ingress Protection	IP10
Depth	11.1mm
Insulation Height	0.298 7.57mm
Current Rating	14.5A
Termination Style	Solder
Approval Agency	CSA, UR
UL Flammability Code	94V-0
Insulation Resistance	1MOhm
Voltage	300V
Contact Tail Length	0.126 3.20mm
Max Current Rating	10A
Number of Levels	1
Current	10A
Number of Poles	8
Contact Mating Finish	Tin
Voltage - IEC	320V
Header Orientation	90°, Right Angle
Current - IEC	17A
Hole Diameter	1.3 mm
Length	29.4mm
Width	11.1mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1605130000 Product Details

1605130000 Overview

This device has a Through Hole mounting type.A Bulk case is used for packaging.The product is a part of the Omnimate SL Series.By Through Hole it's mounted.It runs at -50°C~100°C Operating Temperature.Several of the benefits of this part are also shared by other Header, Male Pins, Shrouded (4 Side) products.
