Name: 1605100000
Brand: Weidmüller
SKU: 1605100000
Price: 2.50000 USD
Availability: InStock

new-10%

1605100000

Manufacturer part number:1605100000

Manufacturer:Weidmüller

Description:1605100000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1605100000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2008
Series	Omnimate SL
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Type	Header, Male Pins, Shrouded (4 Side)
Color	Orange
Number of Rows	1
Gender	Male
Voltage - Rated	300V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.138 3.50mm
Total Number of Contacts	5
Orientation	Right Angle
Ingress Protection	IP10
Depth	11.1mm
Insulation Height	0.298 7.57mm
Current Rating	17A
Termination Style	Solder
Approval Agency	CSA, UR
UL Flammability Code	94V-0
Insulation Resistance	1MOhm
Voltage	300V
Contact Tail Length	0.126 3.20mm
Max Current Rating	10A
Number of Levels	1
Current	10A
Number of Poles	5
Contact Mating Finish	Tin
Voltage - IEC	320V
Header Orientation	90°, Right Angle
Current - IEC	17A
Hole Diameter	1 mm
Length	18.9mm
Width	11.1mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
REACH SVHC	Unknown
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1605100000 Product Details

1605100000 Overview

There is a Through Hole mounting type for the device.Packaging for the product is carried out via a Bulk case.This product is from the Omnimate SL Series.There is a Through Hole mount on the part.Device runs at -50°C~100°C Operating Temperature.There are a lot of similarities between this part and other Header, Male Pins, Shrouded (4 Side) products.
