Name: 1147310000
Brand: Weidmüller
SKU: 1147310000
Price: 0.94000 USD
Availability: InStock

new-10%

1147310000

Manufacturer part number:1147310000

Manufacturer:Weidmüller

Description:1147310000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1147310000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Insulation Material	Nylon
Housing Material	Polyamide (PA), Nylon, Glass Filled
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2015
Series	Omnimate SL
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	3
Color	Orange
Gender	Male
Voltage - Rated	300V
Pitch	0.200 5.08mm
Insulation Height	0.335 8.51mm
Current Rating	24A
Termination Style	Solder
Approval Agency	cURus
Contact Tail Length	0.126 3.20mm
Number of Levels	1
Contact Mating Finish	Tin
Current - UL	18.5A
Voltage - IEC	400V
Header Orientation	90°, Right Angle
Hole Diameter	1.3 mm
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1147310000 Product Details

1147310000 Overview

Mounting type Through Hole is selected for the device.In order to package the product, a Bulk case is used.This is from the Omnimate SL Series.There is a Through Hole mount on the part.There is no operating temperature for the device.There are a number of benefits that this part has in common with other Header, Male Pins, Shrouded (4 Side) products.
