Name: 1146340000
Brand: Weidmüller
SKU: 1146340000
Price: 1.59000 USD
Availability: InStock

new-10%

1146340000

Manufacturer part number:1146340000

Manufacturer:Weidmüller

Description:1146340000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1146340000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Insulation Material	Nylon
Housing Material	Polyamide (PA), Nylon, Glass Filled
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2011
Series	Omnimate SL
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Type	Header, Male Pins, Shrouded (2 Side)
Number of Positions	3
Color	Orange
Gender	Male
Voltage - Rated	300V
Pitch	0.200 5.08mm
Insulation Height	0.472 12.00mm
Current Rating	24A
Termination Style	Solder
Approval Agency	cURus
Contact Tail Length	0.126 3.20mm
Number of Levels	1
Contact Mating Finish	Tin
Current - UL	18.5A
Voltage - IEC	400V
Header Orientation	Vertical
Hole Diameter	1.3 mm
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1146340000 Product Details

1146340000 Overview

A Through Hole mounting type is specified for the device.The product is packaged in a Bulk case.This product is part of the Omnimate SL Series.Through Hole is used to mount the part.Device runs in -50°C~100°C operating temperature.It is a part that shares many benefits with other products from the Header, Male Pins, Shrouded (2 Side) line.
