860160575028

  • 860160575028 - WCAP-ATLL 680μF Capacitor ±20% Tape & Box (TB) Through Hole 1.68A 0.394Dia 10.00mm -55°C~105°C Polar 5.0038mm Radial, Can
  • 860160575028 - WCAP-ATLL 680μF Capacitor ±20% Tape & Box (TB) Through Hole 1.68A 0.394Dia 10.00mm -55°C~105°C Polar 5.0038mm Radial, Can

860160575028

860160575028

Würth Elektronik

WCAP-ATLL 680μF Capacitor ±20% Tape & Box (TB) Through Hole 1.68A 0.394Dia 10.00mm -55°C~105°C Polar 5.0038mm Radial, Can

SOT-23

860160575028 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 24 Weeks
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Material Aluminium
Operating Temperature-55°C~105°C
PackagingTape & Box (TB)
Series WCAP-ATLL
Size / Dimension 0.394Dia 10.00mm
Tolerance ±20%
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature105°C
Min Operating Temperature -55°C
Applications General Purpose
Voltage - Rated 35V
Capacitance 680μF
Lead Pitch 5.0038mm
Polarity Polar
Lead Spacing0.197 5.00mm
Lifetime @ Temp 6000 Hrs @ 105°C
Ripple Current1.68A
Polarization Polar
Life (Hours) 6000 hours
Impedance84mOhms
Ripple Current @ Low Frequency 974.4mA @ 120Hz
Ripple Current @ High Frequency 1.68A @ 100kHz
Height 25mm
Height Seated (Max) 1.043 26.50mm
RoHS StatusROHS3 Compliant
In-Stock:7762 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.861661$0.861661
10$0.812888$8.12888
100$0.766875$76.6875
500$0.723467$361.7335
1000$0.682516$682.516

860160575028 Product Details

860160575028 Overview
