Name: CMD9322SRVGCTR8
Brand: Visual Communications Company - VCC
SKU: CMD9322SRVGCTR8
Availability: InStock

new-10%

CMD9322SRVGCTR8

Manufacturer part number:CMD9322SRVGCTR8

Manufacturer:Visual Communications Company - VCC

Description:LED GRN/RED CLEAR GULL WING SMD

Case Package:SOT-23

Datasheet:CMD9322SRVGCTR8 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	4-SMD, Gull Wing
Packaging	Tape & Reel (TR)
Published	2009
Size / Dimension	3.40mm Lx2.70mm W
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	2 (1 Year)
Max Operating Temperature	80°C
Min Operating Temperature	-20°C
Color	Green, Red
HTS Code	8541.40.20.00
Power Rating	105mW
Configuration	Independent
Voltage	2.1V
Voltage - Forward (Vf) (Typ)	2.1V Green 1.7V Red
Viewing Angle	125°
Optoelectronic Device Type	DUAL COLOR LED
Forward Current	20mA
Current - Test	20mA Green 20mA Red
Lens Style	Rectangle with Flat Top
Luminous Intensity	40 mcd
Millicandela Rating	20mcd Green, 40mcd Red
Illumination Color	Green, Red
Lens Transparency	Clear
Wavelength - Peak	570nm Green 660nm Red
Reverse Voltage (DC)	5V
Height	1.5mm
RoHS Status	ROHS3 Compliant

About CMD9322SRVGCTR8

The CMD9322SRVGCTR8 from Visual Communications Company - VCC is a high-performance microcontroller designed for a wide range of embedded applications. This component features LED GRN/RED CLEAR GULL WING SMD.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment
