TNPW12063K61BEEA

new-10%

Manufacturer part number:TNPW12063K61BEEA

Manufacturer:Vishay Dale

Description:Thin Film Resistors - SMD 3.61Kohms .1% 25ppm

Case Package:SOT-23

Datasheet:TNPW12063K61BEEA Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Contact Plating	Tin
Package / Case	1206 (3216 Metric)
Supplier Device Package	1206
Operating Temperature	-55°C~155°C
Packaging	Tape & Reel (TR)
Published	2016
Series	TNPW e3
Size / Dimension	0.126Lx0.063W 3.20mmx1.60mm
Tolerance	±0.1%
Feature	Anti-Sulfur, Automotive AEC-Q200, Moisture Resistant
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	SMD/SMT
Temperature Coefficient	±25ppm/°C
Resistance	3.61kOhms
Max Operating Temperature	125°C
Min Operating Temperature	-55°C
Composition	Thin Film
Power (Watts)	0.25W 1/4W
Voltage - Rated	200V
Power Rating	250mW
Max Power Dissipation	250mW
Case Code (Metric)	3216
Case Code (Imperial)	1206
Height	660.4μm
Height Seated (Max)	0.026 0.65mm
Length	3.2004mm
Width	1.6002mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
Ratings	AEC-Q200
