Name: TNPW120618K0BEEN
Brand: Vishay Dale
SKU: TNPW120618K0BEEN
Price: 0.33000 USD
Availability: InStock

new-10%

TNPW120618K0BEEN

Manufacturer part number:TNPW120618K0BEEN

Manufacturer:Vishay Dale

Description:RES SMD 18K OHM 0.1% 1/4W 1206

Case Package:SOT-23

Datasheet:TNPW120618K0BEEN Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Contact Plating	Tin
Mount	Surface Mount
Package / Case	1206 (3216 Metric)
Supplier Device Package	1206
Operating Temperature	-55°C~155°C
Packaging	Tape & Reel (TR)
Published	2009
Series	TNPW e3
Size / Dimension	0.126Lx0.063W 3.20mmx1.60mm
Tolerance	±0.1%
Feature	Anti-Sulfur, Automotive AEC-Q200, Moisture Resistant
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	SMD/SMT
Temperature Coefficient	±25ppm/°C
Resistance	18kOhms
Max Operating Temperature	125°C
Min Operating Temperature	-55°C
Composition	Thin Film
Power (Watts)	0.25W 1/4W
Voltage - Rated	200V
Power Rating	250mW
Voltage - Rated DC	100V
Max Power Dissipation	250mW
Depth	1.6mm
Military Standard	Not
Case Code (Metric)	3216
Case Code (Imperial)	1206
Height	660.4μm
Height Seated (Max)	0.026 0.65mm
Length	3.2mm
Width	1.6mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Ratings	AEC-Q200

About TNPW120618K0BEEN

The TNPW120618K0BEEN from Vishay Dale is a high-performance microcontroller designed for a wide range of embedded applications. This component features RES SMD 18K OHM 0.1% 1/4W 1206.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the TNPW120618K0BEEN, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
