Name: UA78M12CKTP
Brand: Texas Instruments
SKU: UA78M12CKTP
Price: 0.20000 USD
Availability: InStock

new-10%

UA78M12CKTP

Manufacturer part number:UA78M12CKTP

Manufacturer:Texas Instruments

Description:2.3mm PMIC 3

Case Package:SOT-23

Datasheet:UA78M12CKTP Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Surface Mount	YES
JESD-609 Code	e0
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	TIN LEAD
HTS Code	8542.39.00.01
Subcategory	Other Regulators
Technology	BIPOLAR
Terminal Position	SINGLE
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	220
Number of Functions	1
Terminal Pitch	2.3mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Pin Count	3
JESD-30 Code	R-PSSO-G2
Number of Outputs	1
Qualification Status	Not Qualified
Quiescent Current	4.8mA
Output Voltage 1	12V
Input Voltage (Min)	14.5V
Input Voltage (Max)	30V
Dropout Voltage	2V
Dropout Voltage1-Nom	2.5V
Output Voltage1-Max	12.6V
Output Voltage1-Min	11.4V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR
Voltage Tolerance-Max	5%
Output Current1-Max	0.5A
Operating Temperature TJ-Max	125°C
Input Voltage Absolute-Max	35V
Adjustability	FIXED
Load Regulation-Max(%)	0.24%
Line Regulation-Max (%/V)	0.1%
Length	6.145mm
Height Seated (Max)	2.16mm
Width	6.04mm
RoHS Status	RoHS Compliant
Lead Free	Contains Lead

UA78M12CKTP Product Details

UA78M12CKTP Overview

There are 2 terminations on the battery regulator IC chip and each of them has its own function. It has a total of 3 pins on IC voltage regulator. In order to ensure prompt, adequate, and prompt performance, this regulator has 1 outputs in total. In terms of its dropout voltage, it is 10 volts. In this instance, we are dealing with a typical Other Regulators-shaped component. It is worth mentioning that the regulator type for this regulator IC is FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR. It operates in the 4.8mA Quiescent Current state.
