Name: TRS211CDWG4
Brand: Texas Instruments
SKU: TRS211CDWG4
Availability: InStock

Technical Specifications

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	28-SOIC (0.295, 7.50mm Width)
Number of Pins	28
Weight	730.794007mg
Operating Temperature	0°C~70°C
Packaging	Tube
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	28
ECCN Code	EAR99
Type	Transceiver
Subcategory	Line Driver or Receivers
Voltage - Supply	4.5V~5.5V
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Number of Functions	4
Supply Voltage	5V
Terminal Pitch	1.27mm
[email protected] Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	TRS211
Pin Count	28
Qualification Status	Not Qualified
Operating Supply Voltage	5V
Power Supplies	5V
Supply Current-Max	20mA
Data Rate	120Kbps
Differential Output	NO
Protocol	RS232
Input Characteristics	SCHMITT TRIGGER
Number of Drivers/Receivers	4/5
Duplex	Full
Receiver Hysteresis	500mV
Number of Drivers	4
Receive Delay-Max	10000 ns
Output Low Current-Max	0.0016A
Number of Receivers	5
Out Swing-Min	10 V
High Level Input Current-Max	0.0002A
Length	17.9mm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

TRS211CDWG4 Product Details

TRS211CDWG4 Overview

LED drivers benefit from this IC's enhanced 28-SOIC (0.295, 7.50mm Width) package.The package of this receiver is Tube.Being a Transceiver can transceiver, this part has empowered many solutions to serve for a variety of applications.Ideally, you should place this wide receiver on a Surface Mount-type PCB or development board.A differential driver like this uses 4.5V~5.5V of power.This electronic part can have?up to 4/5 eligible receivers/drivers on the field at once.?IC receiver's like this are designed for applications requiring a 0°C~70°C operating temperature.An operating voltage range of 5V is suitable for this line driver ic.The integrated terminations of this wide receiver allow it to drive and receive signals from data.The pinouts for this transceiver are standardized to meet the needs of the market.You can search with TRS211 to get more variants of this part, since it identifies the product type, temperature, package, etc.An enhanced power dissipation control is provided by this 28-pin driver IC.The package size of this optical transceiver has been dramatically reduced by downsizing ICs and using high-density Surface Mount mounting techniques.As a result of the design of this transceiver module, the input voltage supply is designed to operate at 5V.3 volts.There is a subcategory called Line Driver or Receivers for this rf transceiver module.It is designed so that it can be operated from a 5V power supply with this driver IC.This rf transceiver module can have?up to 5 eligible receivers on the field at once.?The integrator circuit comes with embedded 4 drivers.Ensure that the VCC pin of the ic receiver receives sufficient but not more than 20mA of input current.
