Name: TPS74401MRGWREP
Brand: Texas Instruments
SKU: TPS74401MRGWREP
Price: 20.74000 USD
Availability: InStock

new

TPS74401MRGWREP

Manufacturer part number:TPS74401MRGWREP

Manufacturer:Texas Instruments

Description:Enable, Power Good, Soft Start Adjustable TPS74401 PMIC 20 20-VQFN Exposed Pad

Case Package:SOT-23

Datasheet:TPS74401MRGWREP Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 4 days ago)
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	20-VQFN Exposed Pad
Surface Mount	YES
Number of Pins	20
Operating Temperature	-55°C~125°C
Packaging	Tape & Reel (TR)
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	20
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Packing Method	TR
Terminal Position	QUAD
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Base Part Number	TPS74401
Pin Count	20
Number of Outputs	1
Voltage - Input (Max)	5.5V
Output Voltage	3.6V
Output Type	Adjustable
Max Output Current	3A
Output Configuration	Positive
Quiescent Current	3mA
Control Features	Enable, Power Good, Soft Start
Accuracy	1 %
Max Output Voltage	3.6V
Voltage - Output (Min/Fixed)	0.8V
Number of Regulators	1
Min Input Voltage	800mV
Protection Features	Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Voltage Dropout (Max)	0.24V @ 3A
PSRR	73dB ~ 50dB (1kHz ~ 800kHz)
Reference Voltage	808mV
Dropout Voltage	240mV
Dropout Voltage1-Nom	0.115V
Min Output Voltage	800mV
Power Supply Rejection Ratio (PSRR)	50dB
Min Current Limit	3.7A
Output Voltage Accuracy	0.2 %
Height	1mm
Length	5mm
Width	5mm
Thickness	900μm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

TPS74401MRGWREP Product Details

TPS74401MRGWREP Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a 20-VQFN Exposed Pad package. There are 20 terminations on the gadget. The IC chip's output type is Adjustable. This electronic component implements 1 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -55°C~125°C degrees. This regulator's output function is configured to be Positive. IC voltage regulator has a sum of 20 pins. To ensure prompt, sufficient performance, this part features 1 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 20. FYI, the basic part number for this IC regulator is TPS74401. The way of packing the voltage regulator IC is TR. It works in 3A output current at mostIt operates in the 3mA Quiescent Current state.
