Name: TPS70251PWPRG4
Brand: Texas Instruments
SKU: TPS70251PWPRG4
Availability: InStock

new-10%

TPS70251PWPRG4

Manufacturer part number:TPS70251PWPRG4

Manufacturer:Texas Instruments

Description:Enable, Power Good, Reset, Sequencing Fixed 0.65mm TPS70251 PMIC 20 20-PowerTSSOP (0.173, 4.40mm Width)

Case Package:SOT-23

Datasheet:TPS70251PWPRG4 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	20-PowerTSSOP (0.173, 4.40mm Width)
Surface Mount	YES
Number of Pins	20
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	20
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Packing Method	TR
Max Power Dissipation	4.115W
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.65mm
Base Part Number	TPS70251
Pin Count	20
Current - Supply (Max)	230μA
Number of Outputs	2
Voltage - Input (Max)	6V
Output Voltage	1.8V
Output Type	Fixed
Max Output Current	500mA
Output Configuration	Positive
Current - Output	500mA 250mA
Quiescent Current	190μA
Control Features	Enable, Power Good, Reset, Sequencing
Accuracy	2 %
Max Output Voltage	3.3V
Output Voltage 1	3.3V
Voltage - Output (Min/Fixed)	3.3V 1.8V
Number of Regulators	2
Min Input Voltage	2.7V
Protection Features	Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Voltage Dropout (Max)	0.28V @ 500mA -
PSRR	60dB (1KHz), 50dB (1kHz)
Dropout Voltage	170mV
Dropout Voltage1-Nom	0.17V
Min Output Voltage	3.3V
Voltage Tolerance-Max	2%
Input Bias Current	190μA
Output Voltage 2	1.8V
Height	1.2mm
Length	6.5mm
Width	4.4mm
Thickness	1mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

TPS70251PWPRG4 Product Details

TPS70251PWPRG4 Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a 20-PowerTSSOP (0.173, 4.40mm Width) package. There are 20 terminations on the gadget. The IC chip's output type is Fixed. This electronic component implements 2 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~125°C degrees. This regulator's output function is configured to be Positive. Its current output stands at 500mA 250mA. IC voltage regulator has a sum of 20 pins. To ensure prompt, sufficient performance, this part features 2 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 20. FYI, the basic part number for this IC regulator is TPS70251. The way of packing the voltage regulator IC is TR. It works in 500mA output current at mostIt operates in the 190μA Quiescent Current state.
