Name: TMS370C742AFNTG4
Brand: Texas Instruments
SKU: TMS370C742AFNTG4
Availability: InStock

new-10%

TMS370C742AFNTG4

Manufacturer part number:TMS370C742AFNTG4

Manufacturer:Texas Instruments

Description:8KB 8K x 8 OTP 8-Bit Microcontroller TMS370 Series 370C742 44 Pin 5MHz 5V 44-LCC (J-Lead)

Case Package:SOT-23

Datasheet:TMS370C742AFNTG4 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	44-LCC (J-Lead)
Number of Pins	44
Operating Temperature	-40°C~105°C TA
Packaging	Tube
Series	TMS370
JESD-609 Code	e4
Pbfree Code	no
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	44
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Max Power Dissipation	1W
Terminal Position	QUAD
Terminal Form	J BEND
Peak Reflow Temperature (Cel)	260
Supply Voltage	5V
Frequency	5MHz
Base Part Number	370C742
Pin Count	44
Supply Voltage-Max (Vsup)	5.5V
Supply Voltage-Min (Vsup)	4.5V
Memory Size	8kB
Oscillator Type	Internal
Number of I/O	27
RAM Size	256 x 8
Memory Type	EPROM, OTP
Voltage - Supply (Vcc/Vdd)	4.5V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Peripherals	PWM, WDT
Program Memory Type	OTP
Core Size	8-Bit
Program Memory Size	8KB 8K x 8
Connectivity	SCI
Bit Size	8
Data Converter	A/D 8x8b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
Number of Timers/Counters	2
EEPROM Size	256 x 8
Number of UART Channels	1
Number of ADC Channels	8
Height	4.06mm
Length	16.66mm
Width	16.66mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Contains Lead

TMS370C742AFNTG4 Product Details

TMS370C742AFNTG4 Overview

There is a 44-LCC (J-Lead) package available. The board has 27 I/Os. Using the Mounting Type Surface Mount, the MCU is mounted on PCB. A 8-Bit core is used in order to power the IC chip. The type of memory it uses for its program is OTP. -40°C~105°C TA is the temperature range at which this Microcontroller operates. TMS370-series components are electrical components. In the case of this Microcontroller, the memory size of the program is 8KB 8K x 8. Microcontroller's a MICROCONTROLLER uPs/uCs/Peripheral IC. IC Chip terminations are 44. As a result, this Microcontroller comes with a 8-bit size. Input voltage for the chip is 5V volts. A total of NO DMA channels are available. This IC part has a memory size of 8kB. There are a number of alternatives to the base part number 370C742 that you can find. Performing well when operated at frequency 5MHz can be achieved. Using YES PWM channels, the device works. On the chip, there are 44 pins that can be accessed. It comes with 2 timers/counters that can be set up. The pins counted are 44. EPROM, OTP memory is one of the features of this equipment. In addition, it has 8 UART channels to choose from. The device has a total of 8 ADC channels in total.
