Name: TLC2654IN
Brand: Texas Instruments
SKU: TLC2654IN
Availability: InStock

new-10%

TLC2654IN

Manufacturer part number:TLC2654IN

Manufacturer:Texas Instruments

Description:125 dB Instrumentational OP Amps 0.0002μA 14 Pins

Case Package:SOT-23

Datasheet:TLC2654IN Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Surface Mount	NO
JESD-609 Code	e4
Number of Terminations	14
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code	8542.33.00.01
Terminal Position	DUAL
Terminal Form	THROUGH-HOLE
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Number of Functions	1
Supply Voltage	5V
Terminal Pitch	2.54mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Pin Count	14
JESD-30 Code	R-PDIP-T14
Qualification Status	Not Qualified
Operating Temperature (Max)	85°C
Operating Temperature (Min)	-40°C
Power Supplies	+-5V
Temperature Grade	INDUSTRIAL
Supply Current-Max	2.2mA
Slew Rate	2 V/us
Architecture	CHOPPER-STAB
Amplifier Type	OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio	125 dB
Neg Supply Voltage-Nom (Vsup)	-5V
Unity Gain BW-Nom	1900 kHz
Average Bias Current-Max (IIB)	0.0002μA
Low-Offset	YES
Frequency Compensation	YES
Supply Voltage Limit-Max	8V
Low-Bias	YES
Micropower	NO
Bias Current-Max (IIB) @25C	0.0002μA
Programmable Power	NO
Input Offset Voltage-Max	40μV
Wideband	NO
Power	NO
Voltage Gain-Min	1000000
Common-mode Reject Ratio-Min	105 dB
Slew Rate-Min	1.2 V/us
Length	19.305mm
Height Seated (Max)	5.08mm
Width	7.62mm
RoHS Status	Non-RoHS Compliant

TLC2654IN Product Details

TLC2654IN Overview
