SN74LV04ARGYR Overview
The part can be shipped overseas conveniently because it is packaged in 14-VFQFN Exposed Pad. In order to provide high reliability, an advanced packaging method Cut Tape (CT) is used. As a result, it works on the principle of Inverter. The part must have a voltage of 2V~5.5V in order to function properly. Operating temperature around -40°C~85°C extended. Surface Mount is the mounting position of the part. In the low and high states of output current, the current is 12mA 12mA. This is part of the 74LV series. In total, there are 14 terminations. 6 functions in the part enhance the user experience significantly. The chip is part of the LV/LV-A/LVX/H family. Use 74LV04 to search for device variants. There are 14 pins injected into the part body. Many applications use this logic device with Surface Mount mounting. The functions of 14 pins can be found in the datasheets. When the part is quiescent, 20μA current flows through it. It has a load capacitance of 50pF. Devices require a minimum voltage of 2V. There is an industry TR method included. The datasheet specifies that the part requires 3.3V volts of power. 12mA is the device's output current rating. The operation uses 6 elements in total. It is specified that the operating supply voltage for the chip will be 5V volts.
SN74LV04ARGYR Features
Inverter Logic Type
Operating Temperature: -40°C~85°C
LV/LV-A/LVX/H Family
Quiescent Current: 20μA
Output Current: 12mA
SN74LV04ARGYR Applications
There are a lot of Texas Instruments
SN74LV04ARGYR Gates and Inverters applications.
- Electrical tools
- Sewing machine
- DVD
- VCD
- Computer
- Television
- Washing machine
- Range hood
- Refrigerator
- VCR
