SN74AS808BN Overview
As the part is packed in 20-DIP (0.300, 7.62mm), international shipping is convenient. A high level of reliability can be achieved through the use of an advanced packaging method Tube. This logic works according to the AND Gate principle. Ensure the part's full functionality by setting the voltage to 4.5V~5.5V. Operating temperature extended to 0°C~70°C. It is mounted in position Through Hole. 48mA 48mA is the output current's high and low states. 74AS is its series number. Total terminations are 20. Users will benefit significantly from 6 functions in this part. There is a chip like this in AS. Trying searching with 74AS808 will yield device variants. The part body receives 20 pins. The logic device can be mounted on the Through Hole axis and is used in a wide range of applications. Datasheets for 20 pin functions are available upon request. Inputs for the part are set to 2. Quiescent parts carry 20mA current. Part now bears a 50pF load capacitance. A 5V power supply is specified in the datasheet for this part. A device with an output current of 48mA is rated. This device includes 1 outputs. For operation, 6 elements are used. There is a specification for the operating voltage of the chip, 5VV, which is referred to as the supply voltage.
SN74AS808BN Features
AND Gate Logic Type
Operating Temperature: 0°C~70°C
AS Family
Quiescent Current: 20mA
Output Current: 48mA
