SN74ABTH16823DGGR Overview
56-TFSOP (0.240, 6.10mm Width)is the packaging method. Package Cut Tape (CT)embeds it. As configured, the output uses Tri-State, Non-Inverted. In the configuration of the trigger, Positive Edgeis used. It is mounted in the way of Surface Mount. A 4.5V~5.5Vsupply voltage is required for it to operate. Temperature is set to -40°C~85°C TA. D-Typedescribes this flip flop. FPGAs belonging to the 74ABTHseries contain this type of chip. Its output frequency should not exceed 150MHz Hz. A total of 2elements are present in it. There is a consumption of 500μAof quiescent energy. There have been 56 terminations. The 74ABTH16823family includes it. Power is provided by a 5V supply. This T flip flop has a capacitance of 4pF farads at the input. An electronic device belonging to the family ABTcan be found here. There is an electronic part that is mounted in the way of Surface Mount. A total of 56pins are provided on this board. This device's clock edge trigger type is Positive Edge. It is part of the FF/Latchesbase part number family. It is designed with a number of bits of 9. Compared to other similar T flip flops, this device offers reliable performance and is well suited for TAPE AND REEL. The D latch runs on a voltage of 5V volts. There are 2 terminations, which are the practice of ending a transmission line with a device that matches the characteristic impedance of the line. High efficiency requires the supply voltage to be maintained at 5V. With an output current of 64mA, this device offers maximum design flexibility. There are 3 output lines on it. Currently, there are 9 lines of input. As an additional reference, you may refer to electronic flip flop WITH CLEAR AND CLOCK ENABLE.
SN74ABTH16823DGGR Features
Cut Tape (CT) package
74ABTH series
56 pins
9 Bits
5V power supplies
SN74ABTH16823DGGR Applications
There are a lot of Texas Instruments SN74ABTH16823DGGR Flip Flops applications.
- Convert a momentary switch to a toggle switch
- Buffered Clock
- Shift registers
- Computers
- Cold spare funcion
- EMI reduction circuitry
- Load Control
- Supports Live Insertion
- Guaranteed simultaneous switching noise level
- Common Clocks
