Name: MSP430FR2422IRHLR
Brand: Texas Instruments
SKU: MSP430FR2422IRHLR
Price: 1.62000 USD
Availability: InStock

new-10%

MSP430FR2422IRHLR

Manufacturer part number:MSP430FR2422IRHLR

Manufacturer:Texas Instruments

Description:7.5KB 7.5K x 8 FRAM MSP430 16-Bit Microcontroller MSP430™ FRAM Series 20 Pin 3V 20-VFQFN Exposed Pad

Case Package:SOT-23

Datasheet:MSP430FR2422IRHLR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	20-VFQFN Exposed Pad
Surface Mount	YES
Number of Pins	20
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	MSP430™ FRAM
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	20
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3V
Terminal Pitch	0.5mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Supply Voltage-Max (Vsup)	3.6V
Oscillator Type	Internal
Number of I/O	15
Speed	16MHz
RAM Size	2K x 8
Voltage - Supply (Vcc/Vdd)	2V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	MSP430
Peripherals	Brown-out Detect/Reset, PWM, WDT
Program Memory Type	FRAM
Core Size	16-Bit
Program Memory Size	7.5KB 7.5K x 8
Connectivity	I2C, IrDA, SCI, SPI, UART/USART
Bit Size	16
Data Converter	A/D 8x10b
Has ADC	YES
DMA Channels	NO
PWM Channels	YES
DAC Channels	NO
ROM (words)	7680
Number of UART Channels	1
Height	1mm
Length	4.5mm
Width	3.5mm
Thickness	900μm
RoHS Status	ROHS3 Compliant

MSP430FR2422IRHLR Product Details

MSP430FR2422IRHLR Description

MSP430FR2422IRHLR, manufactured by Texas. It's category belong to Microcontrollers - MCU. It is applied to many fields, like Automotive Hybrid, electric & powertrain systems Industrial Electronic point of sale (EPOS) Enterprise systems Data center & enterprise computing . And the main parameters of this part is: 16 MHz MCU with 8KB FRAM, 2KB SRAM, 10-bit ADC, UART/SPI/I2C, timer 20-VQFN -40 to 85. Additionally, it is green and compliant to RoHS (Lead free / RoHS Compliant).
