Name: MSP430F2274TDA
Brand: Texas Instruments
SKU: MSP430F2274TDA
Price: 7.92000 USD
Availability: InStock

new-10%

MSP430F2274TDA

Manufacturer part number:MSP430F2274TDA

Manufacturer:Texas Instruments

Description:32KB 32K x 8 + 256B FLASH MSP430 16-Bit Microcontroller MSP430F2xx Series 38 Pin 16MHz 2.2V 38-TSSOP (0.240, 6.10mm Width)

Case Package:SOT-23

Datasheet:MSP430F2274TDA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 1 week ago)
Factory Lead Time	6 Weeks
Contact Plating	Gold
Mounting Type	Surface Mount
Package / Case	38-TSSOP (0.240, 6.10mm Width)
Surface Mount	YES
Number of Pins	38
Weight	203.804722mg
Operating Temperature	-40°C~105°C TA
Packaging	Tube
Series	MSP430F2xx
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	38
ECCN Code	EAR99
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	2.2V
Terminal Pitch	0.65mm
Frequency	16MHz
Pin Count	38
Supply Voltage-Max (Vsup)	3.6V
Supply Voltage-Min (Vsup)	3.3V
Interface	I2C, IrDA, LIN, SCI, SPI, UART, USART
Memory Size	32kB
Oscillator Type	Internal
Number of I/O	32
RAM Size	1K x 8
Voltage - Supply (Vcc/Vdd)	1.8V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	MSP430
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	32KB 32K x 8 + 256B
Connectivity	I2C, IrDA, LINbus, SCI, SPI, UART/USART
Supply Current-Max	0.55mA
Bit Size	16
Data Converter	A/D 12x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Boundary Scan	YES
Low Power Mode	YES
Number of A/D Converters	12
Format	FIXED-POINT
Integrated Cache	NO
RAM (words)	1
Number of Serial I/Os	2
Number of Timers	6
Number of I2C Channels	1
Number of SPI Channels	2
Height	1.2mm
Length	12.5mm
Width	6.2mm
Thickness	1.15mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

MSP430F2274TDA Product Details

MSP430F2274TDA Description
