Name: LP3913SQX-AE/NOPB
Brand: Texas Instruments
SKU: LP3913SQX-AE/NOPB
Availability: InStock

Technical Specifications

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	48-WFQFN Exposed Pad
Number of Pins	48
Operating Temperature	-40°C~85°C
Packaging	Tape & Reel (TR)
JESD-609 Code	e3
Pbfree Code	no
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	48
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Applications	Handheld/Mobile Devices
Additional Feature	POWER-ON RESET THRESHOLD 1.9V; ALSO REQUIRES SUPPLY 4.35V TO 6V;
HTS Code	8542.39.00.01
Subcategory	Power Management Circuits
Voltage - Supply	2.5V~6V
Terminal Position	QUAD
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Supply Voltage	5V
Terminal Pitch	0.4mm
Base Part Number	LP3913
Supply Voltage-Max (Vsup)	6V
Power Supplies	5V
Supply Voltage-Min (Vsup)	2.5V
Number of Channels	10
Analog IC - Other Type	POWER SUPPLY SUPPORT CIRCUIT
Adjustable Threshold	YES
Quiescent Current	30μA
Height Seated (Max)	0.8mm
Length	6mm
Width	6mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Contains Lead

LP3913SQX-AE/NOPB Product Details

LP3913SQX-AE/NOPB Overview

It is acceptable to ship in the direction of Tape & Reel (TR) .For ease of transportation, it is packaged the power management in 48-WFQFN Exposed Pad .The Surface Mount mounting method facilitates easy adaptation.Applications targeting this power management include Handheld/Mobile Devices and others.It is recommended that the operating temperature of the power management ic be set to -40°C~85°C to prevent malfunctions.2.5V~6V voltage is used for the operation of this power management.Check out search LP3913 for more power ic's pin-to-pin solutions.On the power management, you can find 48 terminals.It has been praised for its accuracy as a POWER SUPPLY SUPPORT CIRCUIT analog IC.The power managment ic is programmed with 48 pins.In order to mount the integrated power supplies on PCBs or other boards, it has a Surface Mount .The power manager is supplied with 5V voltage and is capable of performing a wide range of demanding tasks.Other Power Management Circuits like the power ic play a important role in the industry.In order for it to come up, the ic supplies must have at least 2.5V .A network of 10 channels maintains the quality of output by cooperating together.In addition, you should not supply the power supply ic with a voltage greater than 6V .The power management chip can be run with 5V power supplies.It is also possible to find POWER-ON RESET THRESHOLD 1.9V; ALSO REQUIRES SUPPLY 4.35V TO 6V; using this integrated power supplies.

LP3913SQX-AE/NOPB Features

Mainly used in Handheld/Mobile Devices applications
Operating temperature: -40°C~85°C
POWER SUPPLY SUPPORT CIRCUIT analog IC
POWER-ON RESET THRESHOLD 1.9V; ALSO REQUIRES SUPPLY 4.35V TO 6V;
