LM358TPX Overview
The instrumentation amplifier in this picture is of the OPERATIONAL AMPLIFIER-type. A Tape and Reel case is used for delivering the op amp. During the past two weeks, there have been close to 8 terminations. A total of 8 pins are located on this board. This linear amplifier should be powered by an 5V battery. This particular linear amplifier is a type of Operational Amplifier device, to be precise. The op amp ic has an array of 8 pins on it. Op amp rates 7mV as input offset voltage. You should keep the voltage gain at 100dB for the time being. On the buffer amps, there are 2 channels that can be used. To operate this buffer amplifier, the temperature must not be lower than 0°C. A temperature greater than 70°C should not be used for the operation of buffer amplifier. This electric component can work from a voltage of under 32V as far as supply voltage is concerned. A voltage of 3V or higher is recommended for the linear amplifier's supply voltage. This electrical part should be conducted under the dual supply voltage of 16V volts when you conduct this part.
LM358TPX Features
8 Pins
supply voltage of 5V
100dB voltage gain
LM358TPX Applications
There are a lot of Texas Instruments
LM358TPX Instrumentational OP Amps applications.
- Multiplication circuits
- Division circuits
- Precision measurement
- Power control
- Information processing
- Weak signal detection
- Signal amplification
- Signal filtering
- Signal operation
- Video computer boards
