Name: LM2937ESX-15
Brand: Texas Instruments
SKU: LM2937ESX-15
Availability: InStock

new-10%

LM2937ESX-15

Manufacturer part number:LM2937ESX-15

Manufacturer:Texas Instruments

Description:Fixed 2.54mm LM2937 PMIC 4 TO-263-4, D2Pak (3 Leads + Tab), TO-263AA

Case Package:SOT-23

Datasheet:LM2937ESX-15 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Number of Pins	3
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
JESD-609 Code	e0
Pbfree Code	no
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	3
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
Subcategory	Other Regulators
Packing Method	TAPE AND REEL
Technology	BIPOLAR
Terminal Position	SINGLE
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	235
Number of Functions	1
Terminal Pitch	2.54mm
Base Part Number	LM2937
Pin Count	4
Current - Supply (Max)	20mA
Number of Outputs	1
Voltage - Input (Max)	26V
Output Voltage	15V
Output Type	Fixed
Max Output Current	500mA
Output Configuration	Positive
Quiescent Current	2mA
Accuracy	5 %
Output Voltage 1	15V
Voltage - Output (Min/Fixed)	15V
Number of Regulators	1
Protection Features	Over Temperature, Reverse Polarity, Short Circuit
Voltage Dropout (Max)	1V @ 50mA
Dropout Voltage	500mV
Dropout Voltage1-Nom	0.5V
Voltage Tolerance-Max	5%
Input Voltage Absolute-Max	26V
Output Voltage Accuracy	5 %
Height Seated (Max)	4.8mm
Width	8.64mm
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead

LM2937ESX-15 Product Details

LM2937ESX-15 Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a TO-263-4, D2Pak (3 Leads + Tab), TO-263AA package. There are 3 terminations on the gadget. The IC chip's output type is Fixed. This electronic component implements 1 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~125°C degrees. This regulator's output function is configured to be Positive. IC voltage regulator has a sum of 4 pins. To ensure prompt, sufficient performance, this part features 1 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 3. FYI, the basic part number for this IC regulator is LM2937. This regulator IC is a typical Other Regulators. The way of packing the voltage regulator IC is TAPE AND REEL. It works in 500mA output current at mostIt operates in the 2mA Quiescent Current state.
