Name: LM218D
Brand: Texas Instruments
SKU: LM218D
Availability: InStock

new-10%

LM218D

Manufacturer part number:LM218D

Manufacturer:Texas Instruments

Description:100 dB Instrumentational OP Amps 0.5μA 8 Pins SOIC

Case Package:SOT-23

Datasheet:LM218D Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Package / Case	SOIC
Surface Mount	YES
Number of Terminations	8
ECCN Code	EAR99
HTS Code	8542.33.00.01
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Number of Functions	1
Supply Voltage	15V
Terminal Pitch	1.27mm
Reach Compliance Code	not_compliant
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Pin Count	8
JESD-30 Code	R-PDSO-G8
Qualification Status	Not Qualified
Operating Temperature (Max)	85°C
Operating Temperature (Min)	-25°C
Power Supplies	+-5/+-20V
Temperature Grade	OTHER
Supply Current-Max	8mA
Slew Rate	70 V/us
Architecture	VOLTAGE-FEEDBACK
Amplifier Type	OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio	100 dB
Neg Supply Voltage-Nom (Vsup)	-15V
Unity Gain BW-Nom	15000 kHz
Average Bias Current-Max (IIB)	0.5μA
Low-Offset	NO
Frequency Compensation	YES
Supply Voltage Limit-Max	20V
Bias Current-Max (IIB) @25C	0.25μA
Neg Supply Voltage-Max (Vsup)	-20V
Input Offset Voltage-Max	6000μV
Voltage Gain-Min	25000
Common-mode Reject Ratio-Min	80 dB
Slew Rate-Min	50 V/us
Length	4.9mm
Height Seated (Max)	1.75mm
Width	3.9mm
RoHS Status	Non-RoHS Compliant

LM218D Product Details

LM218D Overview

In order to protect the op amps, a SOIC case is used. There are two types of operational amplifiers in this circuit. In recent months, the number of terminations has approached 8. It consists of a total of 8 pins in total. It would be helpful if you could remember that this op amp ic should be powered by an 15V battery. A minimum voltage gain of 25000 is the minimum voltage gain that this instrumentation amplifier is capable of producing.
