LM1086CSX-2.5 DESCRIPTION
The LT 1763 series are micropower.lownoise.lowdropout regulators.The devices are capable of supplying 500mA of output current with a dropout voltage of 300mVDesigned for use in battery-poweredsystemsthelow 30uAquiescent current makes them an ideal choice.Quiescent current is well controlled: it does not rise in dropout as it does with many other regulators.
LM1086CSX-2.5 FEATURES
Low Noise:20uVms(10Hz to 100kHz) Output Current:500mA
Low Quiescent Current:30uA
Wide Input Voltage Range:1.8Vto20V Low Dropout Voltaqe:300mV
Very Low Shutdown Current:<1uA No Protection Diodes Needed
Fixed Output Voltages: 1.5V1.8V2.5V.3V3.3V5V Adjustable Output from 1.22Vto20V Stable with 3.3uF Output Capacitor
Stable with Aluminum.Tantalum or Ceramic Capacitors
Reverse Battery Protection No Reverse Current
Overcurrent and Overtemperature Protected8-Lead SO and 12-Lead(4mmx3mm)DFN Packages
LM1086CSX-2.5 APPLICATIONS
Cellular Phones
Battery-Powered Systems
Noise-SensitiveInstrumentation Systems
