Name: COP8SBR9HVA8
Brand: Texas Instruments
SKU: COP8SBR9HVA8
Availability: InStock

new-10%

COP8SBR9HVA8

Manufacturer part number:COP8SBR9HVA8

Manufacturer:Texas Instruments

Description:32KB 32K x 8 FLASH COP8 8-Bit Microcontroller COP8™ 8S Series COP8SBR9 44 Pin 20MHz 4.5V 44-LCC (J-Lead)

Case Package:SOT-23

Datasheet:COP8SBR9HVA8 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	44-LCC (J-Lead)
Surface Mount	YES
Number of Pins	44
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	COP8™ 8S
JESD-609 Code	e0
Pbfree Code	no
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	2A (4 Weeks)
Number of Terminations	44
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Position	QUAD
Terminal Form	J BEND
Peak Reflow Temperature (Cel)	220
Supply Voltage	4.5V
Terminal Pitch	1.27mm
Frequency	20MHz
Base Part Number	COP8SBR9
Pin Count	44
Supply Voltage-Max (Vsup)	5.5V
Supply Voltage-Min (Vsup)	2.7V
Interface	SPI, UART, USART
Memory Size	32kB
Oscillator Type	Internal
Number of I/O	37
Speed	2 MHz
RAM Size	1K x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	COP8
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	32KB 32K x 8
Connectivity	Microwire/Plus (SPI), UART/USART
Supply Current-Max	14.7mA
Bit Size	8
Access Time	20 μs
Has ADC	NO
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Number of Timers/Counters	3
Length	16.51mm
Height Seated (Max)	4.57mm
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead

COP8SBR9HVA8 Product Details

COP8SBR9HVA8 Overview
