CDC7005RGZRG4 Overview
Tape & Reel (TR)-method packaging is used for clock ICs. A Clock PLL is included with the 48-VFQFN Exposed Pad package. The frequency generator is capable of withstanding a maximum temperature of 260 during reflowing. 48 terminations can be found in frequency synthesizer. A voltage of 3.3V should be applied to this electronic frequency generator. A clock generator's input is called LVCMOS, LVPECL and it is designed as the input for this clock generator. RF synthesizers based on this clock provide frequencies up to 800MHz maximum. The Surface Mount allows the electrical component to be installed conveniently on the panel. 3.6V would be the maximum supply voltage for this clock generator. The supply voltage for this frequency synthesizer should be kept above 3V for safety considerations. As long as there are 3V~3.6V supply voltages provided, clock generator ic should work. By calculating the test statistics, -40°C~85°C is the appropriate ambient temperature. In this case, we are dealing with a frequency synthesizer that can be used with LVPECL logic levels. This electronic component is usually classified as a Clock Synchronizer and Jitter Cleaner component. It is a 48-bit IC that is designed for microprocessors specifically. It is possible to find its related electronic parts by searching for the base part number CDC7005. Clock generator is designed with 48 pins. There is a maximum supply voltage of 3.3V that electronic frequency generator can handle. 5 signal outputs maximi5e the output frequency. Low timing skew is provided by this analog clock generator at maximum 0.06 ns. There are 1 inputs on this clock generator.
CDC7005RGZRG4 Features
Available in the 48-VFQFN Exposed Pad
Supply voltage of 3.3V
Operating supply voltage of 3.3V
CDC7005RGZRG4 Applications
There are a lot of Texas Instruments CDC7005RGZRG4 Clock Generators applications.
- Automatic control
- Test equipment
- Cellular/4G
- Remote telemetry and instrumentation
- High-frequency induction heating
- Smartphones
- Bluetooth transmitters
- Bit synchronization
- Broadcast communication
- Ultrasound diagnosis
