CD74ACT05E Overview
The part can be shipped overseas conveniently because it is packaged in 14-DIP (0.300, 7.62mm). In order to provide high reliability, an advanced packaging method Tube is used. As a result, it works on the principle of Inverter. The part must have a voltage of 4.5V~5.5V in order to function properly. Operating temperature around -55°C~125°C extended. Through Hole is the mounting position of the part. In the low and high states of output current, the current is - 24mA. This is part of the 74ACT series. In total, there are 14 terminations. 6 functions in the part enhance the user experience significantly. The chip is part of the ACT family. Use 74ACT05 to search for device variants. There are 14 pins injected into the part body. Many applications use this logic device with Through Hole mounting. The functions of 14 pins can be found in the datasheets. When the part is quiescent, 4μA current flows through it. It has a load capacitance of 50pF. The datasheet specifies that the part requires 5V volts of power. 24mA is the device's output current rating. It is specified that the operating supply voltage for the chip will be 5V volts. Open Drain is its feature. It outputs high quality logic via its 6 channels.
CD74ACT05E Features
Inverter Logic Type
Operating Temperature: -55°C~125°C
ACT Family
Quiescent Current: 4μA
Output Current: 24mA
CD74ACT05E Applications
There are a lot of Texas Instruments
CD74ACT05E Gates and Inverters applications.
- Electrical tools
- Sewing machine
- DVD
- VCD
- Computer
- Television
- Washing machine
- Range hood
- Refrigerator
- VCR
