CD4049UBDW Overview
Shipping overseas is convenient with the part packed in 16-SOIC (0.295, 7.50mm Width). High reliability is provided by advanced packaging method Tube. Based on the Inverter logic principle, it works. A voltage of 3V~18V is required for the part to function properly. Increasing operating temperature to around -55°C~125°C. In Surface Mount, the part is mounted. There is 4.3mA 24mA output current in the high or low states. The 4000B series contains it. Total terminations are 16. User experience is significantly enhanced by the part's 6 functions. The chip is a part of 4000/14000/40000. Try searching with CD4049 if you're looking for device variants. The part body is injected with 16 pins. This logic device is widely used in a wide variety of applications because it is Surface Mount mounted. For functions related to 16 pins, please refer to the datasheets. The part has 20μA current flowing through it in the quiescent state. 50pF is the load capacitance of the part. A minimum voltage of 5V is required to supply the device. 15V is the maximum supply voltage (Vsup). According to the datasheet, the part requires 5/15V power supply. The device has 6 outputs. Standby mode has a maximum current of 4μA. High-quality logic output is provided by the part's 6 channels.
CD4049UBDW Features
Inverter Logic Type
Operating Temperature: -55°C~125°C
4000/14000/40000 Family
Quiescent Current: 20μA
CD4049UBDW Applications
There are a lot of Texas Instruments
CD4049UBDW Gates and Inverters applications.
