Name: MS3474W24-31PY
Brand: TE Connectivity Deutsch Connectors
SKU: MS3474W24-31PY
Price: 94.56000 USD
Availability: InStock

new

MS3474W24-31PY

Manufacturer part number:MS3474W24-31PY

Manufacturer:TE Connectivity Deutsch Connectors

Description:Receptacle, Male Pins Aluminum Panel Mount 31 Positions Crimp Gold Olive Drab Cadmium Bulk Y Bayonet Lock

Case Package:SOT-23

Datasheet:MS3474W24-31PY Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type	Panel Mount
Mounting Feature	Bulkhead - Front Side Nut
Shell Material	Aluminum
Insert Material	Plastic
Body Material	Aluminium
Operating Temperature	-55°C~200°C
Packaging	Bulk
Series	Military, MIL-DTL-26482 G Series II, AFD
Published	2001
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Crimp
Connector Type	Receptacle, Male Pins
Number of Positions	31
Color	Olive Drab
Applications	Aviation, Automotive, Military
Gender	Receptacle
Voltage - Rated	600V
Additional Feature	COMPATIBLE CONTACT: M39029/4-111
Fastening Type	Bayonet Lock
Contact Finish - Mating	Gold
MIL Conformance	YES
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Total Number of Contacts	31
Orientation	Y
Ingress Protection	Environment Resistant
Current Rating	13A
Military Standard	MIL-DTL-26482
Shell Finish	Olive Drab Cadmium
Shell Size - Insert	24-31
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Contact Gender	Male
Empty Shell	YES
Backshell Type	SOLID
Plating	Nickel
Body Plating	Cadmium
REACH SVHC	Unknown
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Ratings	Environment Resistant, IP67

MS3474W24-31PY Product Details

MS3474W24-31PY Overview

Packaging is Receptacle, Male Pins.Panel Mount is the mounting type.Packaging for the product is carried out via a Bulk case.As a product of the Military, MIL-DTL-26482 G Series II, AFD Series, it can be found in this category.There are also other features such as COMPATIBLE CONTACT: M39029/4-111, to name only a few.In this case, Bulkhead, Front Side Nut, Jam Nut, Panel mounts the part.The device is operating at -55°C~200°C Operating Temperature.
