Name: 5747461-5
Brand: TE Connectivity AMP Connectors
SKU: 5747461-5
Price: 16.25000 USD
Availability: InStock

new

5747461-5

Manufacturer part number:5747461-5

Manufacturer:TE Connectivity AMP Connectors

Description:5747461-5 datasheet pdf and D-Sub Connectors product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:5747461-5 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Lifecycle Status	ACTIVE (Last Updated: 4 days ago)
Contact Material	Phosphor Bronze
Mount	Through Hole
Mounting Type	Through Hole, Right Angle
Contact Shape	Round
Shell Material	Steel
Housing Material	Thermoplastic
Body Material	Plastic
PCB Mounting Orientation	Right Angle
Operating Temperature	-55°C~105°C
Packaging	Tray
Published	2008
Series	AMPLIMITE HD-20
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Receptacle, Female Sockets
Number of Positions	25
Color	Black
Number of Rows	2
Gender	Receptacle
Voltage - Rated	125V
HTS Code	8536.69.40.30
Subcategory	D Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Signal
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	2.7432mm
Total Number of Contacts	25
Orientation	Right Angle
Depth	24.68mm
Current Rating	6A
Reference Standard	UL, CSA
Contact Finish	Gold
Reliability	COMMERCIAL
Number Of PCB Rows	2
PCB Contact Pattern	STAGGERED
UL Flammability Code	94V-0
Lead Length	3.175mm
Empty Shell	NO
Rated Current (Signal)	6A
Row Spacing	2.8448 mm
Flange Feature	Mating Side, Female Screwlock (4-40)
ELV	Compliant
Max Voltage Rating (AC)	250V
Plating	Tin
Connector Style	D-Sub
Number of Ports	1
Sealable	No
Shell Size, Connector Layout	3 DB B
Hole Diameter	3.18 mm
Backset Spacing	0.590 (14.99mm)
Preloaded	Yes
Max Supply Voltage (AC)	250V
Mating Connector Lock	With
Height	11.48mm
Length	53.03mm
Contact Finish Thickness	Flash
PCB Thickness	2.36mm
Material Flammability Rating	UL94 V-0
REACH SVHC	Unknown
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

5747461-5 Product Details

5747461-5 Overview

The packaging is Receptacle, Female Sockets.This device is mounted in the Through Hole, Right Angle position.Packaging is performed using a Tray case.It's part of the AMPLIMITE HD-20 Series.1 ports allow you to manage a lot of stuff.There's a Through Hole on the part.The device is operating at -55°C~105°C Operating Temperature.
