Name: 3-1761606-5
Brand: TE Connectivity AMP Connectors
SKU: 3-1761606-5
Price: 13.21000 USD
Availability: InStock

new

3-1761606-5

Manufacturer part number:3-1761606-5

Manufacturer:TE Connectivity AMP Connectors

Description:3-1761606-5 datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:3-1761606-5 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	9 Weeks
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Contact Material	Phosphor Bronze
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Polybutylene Terephthalate (PBT)
Housing Material	PBT
PCB Mount Retention	Without
Operating Temperature	-65°C~105°C
Packaging	Tube
Published	1998
Series	AMP-Latch
Feature	Keying Slot
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Header
Number of Positions	50
Number of Rows	2
Voltage - Rated	250VAC
Additional Feature	POLARIZED
HTS Code	8536.69.40.40
Fastening Type	Latch Lock/Eject Hooks, Long
Contact Finish - Mating	Gold or Gold-Palladium
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	1A per Contact
Orientation	Vertical
Insulation Height	0.404 10.26mm
Style	Board to Cable/Wire
Number of Positions Loaded	All
Current Rating	1A
Pitch - Mating	0.100 2.54mm
Number of Conductors	ONE
Reference Standard	UL
Reliability	COMMERCIAL
Row Spacing - Mating	0.100 (2.54mm)
Contact Length - Post	0.102 2.60mm
Shrouding	Shrouded - 4 Wall
Number Of PCB Rows	2
Lead Pitch	2.54mm
Contact Finish - Post	Tin
Contact Length - Mating	0.237 6.02mm
PCB Contact Pattern	RECTANGULAR
Contact Gender	Male
UL Flammability Code	94V-0
Housing Color	Blue
Lead Length	2.6mm
Body Depth	0.404 inch
Operating Supply Voltage	250V
Contact Resistance	10mOhm
Insulation Resistance	5GOhm
Mating Contact Pitch	0.1 inch
Max Voltage Rating (AC)	250V
Polarization Key	POLARIZED HOUSING
Dielectric Withstanding Voltage	1000VAC V
Max Voltage Rating (DC)	600V
Contact Current Rating	1A
Circuit Application	Signal
Mating Connector Lock	With
Shrouded End Dimension	3.76 mm
Height	9.19mm
Length	71.12mm
Width	71.1mm
Plating Thickness	FLASH inch
Contact Finish Thickness - Mating	30.0μin 0.76μm
Contact Finish Thickness - Post	100.0μin 2.54μm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

3-1761606-5 Product Details

3-1761606-5 Overview

A Header package is included with it.Mounting type Through Hole is assigned to the device.It is necessary to use a Tube case for packaging the product.This product is from the AMP-Latch Series.There are also other features, like POLARIZED, to name a few.As a result of its Keying Slot feature, it possesses a great deal of power.Mounting of the part is based on Through Hole.The operating supply voltage of this memory is 250V.As a result, the device runs at -65°C~105°C Operating Temperature.
