Name: 2-747704-0
Brand: TE Connectivity AMP Connectors
SKU: 2-747704-0
Price: 7.63000 USD
Availability: InStock

new

2-747704-0

Manufacturer part number:2-747704-0

Manufacturer:TE Connectivity AMP Connectors

Description:2-747704-0 datasheet pdf and D-Sub Connectors product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:2-747704-0 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	25 Weeks
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Contact Material	Brass
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	Metal
Contact Shape	Round
Insulation Material	POLYETHYLENE
Shell Material	Steel
Dielectric Material	Thermoplastic
Shell Material, Finish	Steel, Tin Plated
PCB Mount Retention	With
Operating Temperature	-55°C~105°C
Packaging	Tube
Published	1998
Series	AMPLIMITE HD-20
JESD-609 Code	e3
Feature	Board Lock, Grounding Indents
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Plug, Male Pins
Number of Positions	25
Color	Black
Number of Rows	2
Gender	Male
Voltage - Rated	125V
HTS Code	8536.69.40.30
Subcategory	D Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Signal
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	2.7686mm
Total Number of Contacts	25
Orientation	Vertical
Depth	12.54mm
Current Rating	6A
Shell Finish	TIN
Contact Finish	Gold
Reliability	COMMERCIAL
Approval Agency	UL
Number Of PCB Rows	2
PCB Contact Pattern	STAGGERED
Body Breadth	0.494 inch
UL Flammability Code	94V-0
Lead Length	3.175mm
Empty Shell	NO
Row Spacing	2.8448 mm
Flange Feature	Housing/Shell (4-40)
ELV	Non-Compliant
Max Voltage Rating (AC)	250V
Connector Style	D-Sub
Number of Ports	1
Body Plating	Tin
Max Voltage Rating (DC)	250.25kV
Sealable	No
Shell Size, Connector Layout	3 DB B
Hole Diameter	3.0734 mm
Preloaded	Yes
Max Supply Voltage (DC)	250V
Max Supply Voltage (AC)	250V
Mating Connector Lock	Without
Height	11.83mm
Length	53.03mm
PCB Thickness	1.57mm
Material Flammability Rating	UL94 V-0
RoHS Status	Non-RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Contains Lead

2-747704-0 Product Details

2-747704-0 Overview

This product is packaged in a Plug, Male Pins box.Through Hole is the mounting type for the device.To package the product, we use a Tube case.Specifically, it is one of the products in the AMPLIMITE HD-20 Series.This package contains an enclosed device in the Metal.You can manage a variety of tasks with its 1 ports.This feature makes it more powerful in a number of ways due to its Board Lock, Grounding Indents feature.Through Hole mounts the part.As a result, the device runs at -55°C~105°C Operating Temperature.
