Name: 1734829-5
Brand: TE Connectivity AMP Connectors
SKU: 1734829-5
Price: 0.86000 USD
Availability: InStock

new-10%

1734829-5

Manufacturer part number:1734829-5

Manufacturer:TE Connectivity AMP Connectors

Description:High Performance Interconnect (HPI) Series 1-Row Header Solder Phosphor Bronze Tube Through Hole, Right Angle Tin Polyamide (PA9T), Nylon 9T, Glass Filled 5-Position Board to Cable/Wire 0.1

Case Package:SOT-23

Datasheet:1734829-5 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 4 days ago)
Factory Lead Time	11 Weeks
Contact Material	Phosphor Bronze
Contact Plating	Nickel, Tin
Mount	Through Hole
Mounting Type	Through Hole, Right Angle
Contact Shape	Square
Insulation Material	Polyamide (PA9T), Nylon 9T, Glass Filled
Housing Material	Thermoplastic
PCB Mounting Orientation	Right Angle
PCB Mount Retention	Without
PCB Mount Alignment	Without
Operating Temperature	-25°C~85°C
Packaging	Tube
Series	High Performance Interconnect (HPI)
Published	2006
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	5
Max Operating Temperature	85°C
Min Operating Temperature	-25°C
Color	Natural
Applications	Automotive, General Purpose, Industrial, Medical
Number of Rows	1
Voltage - Rated	125V
Contact Finish - Mating	Tin
Contact Type	Male Pin
Current Rating (Amps)	1A
Pitch	1.2446mm
Orientation	Right Angle
Insulation Height	0.126 3.20mm
Style	Board to Cable/Wire
Number of Positions Loaded	All
Current Rating	800mA
Pitch - Mating	0.049 1.25mm
Insulation Color	Natural
Contact Length - Post	0.091 2.30mm
Shrouding	Shrouded - 4 Wall
Number of Contacts	5
Contact Finish - Post	Tin
Contact Gender	Male
Housing Color	Natural
Lead Length	2.3114mm
Operating Supply Voltage	125V
ELV	Compliant
Plating	Tin
Wire/Cable Type	Discrete
Wire/Cable Gauge	26 AWG
Sealable	No
Contact Current Rating	800mA
Mating Retention	Without
Height	3.2mm
Length	8mm
Width	4.7mm
Plating Thickness	2.54μm
Contact Finish Thickness - Mating	100.0μin 2.54μm
Length - Tail	2.3mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1734829-5 Product Details

1734829-5 Overview

The product comes in a package of Header.Through Hole, Right Angle is the type of mounting for the device.To package the product, a Tube case is used.The product is a member of the High Performance Interconnect (HPI) Series.Use it when the temperature is below 85°C.Temperatures below -25°C are required for this device to operate.The device may be used for the following applications: Automotive, General Purpose, Industrial, Medical.It is mounted by Through Hole.Its operating supply voltage is 125V.It operates at an operating temperature of -25°C~85°C.
