Name: 1-87220-4
Brand: TE Connectivity AMP Connectors
SKU: 1-87220-4
Price: 4.81000 USD
Availability: InStock

new-10%

1-87220-4

Manufacturer part number:1-87220-4

Manufacturer:TE Connectivity AMP Connectors

Description:AMPMODU Mod II Series 1-Row Header Solder Phosphor Bronze Bulk Through Hole Gold Thermoplastic 14-Position Board to Board or Cable 0.090 2.29mm Height

Case Package:SOT-23

Datasheet:1-87220-4 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 2 days ago)
Factory Lead Time	17 Weeks
Contact Material	Phosphor Bronze
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Thermoplastic
PCB Mounting Orientation	Vertical
Operating Temperature	-65°C~105°C
Packaging	Bulk
Series	AMPMODU Mod II
Published	2008
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	14
Number of Rows	1
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Depth	2.54mm
Insulation Height	0.090 2.29mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Current Rating	3A
Pitch - Mating	0.100 2.54mm
Approval Agency	CSA
Contact Length - Post	0.125 3.18mm
Shrouding	Unshrouded
Contact Length - Mating	0.318 8.08mm
Contact Gender	Male
UL Flammability Code	94V-0
Housing Color	Black
Lead Length	3.175mm
Overall Contact Length	0.533 13.55mm
Row Spacing	2.54 mm
ELV	Compliant
Contact Current Rating	3A
Mating Post Length	8.08mm
Keyed	No
Length	35.15mm
Contact Finish Thickness - Mating	30.0μin 0.76μm
Contact Finish Thickness - Post	Flash
PCB Thickness	1.397mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1-87220-4 Product Details

1-87220-4 Overview

The packaging contains Header.There is a Through Hole mounting type for the device.This product is packaged in a case marked Bulk.Product number AMPMODU Mod II belongs to the AMPMODU Mod II Series.There is a Through Hole mount on the part.This device operates at a temperature of -65°C~105°C.
