Name: 1-745496-9
Brand: TE Connectivity AMP Connectors
SKU: 1-745496-9
Price: 15.11000 USD
Availability: InStock

new

1-745496-9

Manufacturer part number:1-745496-9

Manufacturer:TE Connectivity AMP Connectors

Description:1-745496-9 datasheet pdf and D-Sub Connectors product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:1-745496-9 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Lifecycle Status	ACTIVE (Last Updated: 2 days ago)
Contact Material	Phosphor Bronze
Contact Plating	Nickel, Tin
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Package / Case	Metal
Shell Material	Steel
Dielectric Material	Thermoplastic, Glass Filled
Housing Material	Thermoplastic
Shell Material, Finish	Steel, Tin Plated
Operating Temperature	-55°C~105°C
Packaging	Bulk
Published	1999
Series	AMPLIMITE HDE-20
JESD-609 Code	e3
Feature	Grounding Indents
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	25
Termination	IDC, Discrete Wire
Connector Type	Plug, Male Pins
Color	Black
Number of Rows	2
Gender	Male
Subcategory	D Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Signal
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	Varies by WireGAuge
Pitch	1.3716mm
Total Number of Contacts	25
Orientation	Straight
Shielding	Shielded
Depth	22.58mm
Current Rating	1A
Shell Finish	TIN
Reference Standard	UL, CSA
Contact Finish	Gold
Reliability	COMMERCIAL
Body Breadth	0.509 inch
UL Flammability Code	94V-0
Empty Shell	NO
Contact Resistance	30mOhm
Wire Gauge	26-30 AWG
Flange Feature	Housing/Shell (Unthreaded)
ELV	Compliant
Max Voltage Rating (AC)	250V
Plating	Tin
Wire/Cable Type	Round
Connector Style	D-Sub
Number of Ports	1
Shell Size, Connector Layout	3 DB B
Insulation Diameter	1.52 mm
Contact Design	PREASSEM CONN
Preloaded	Yes
Max Supply Voltage (AC)	250V
Length	53.41mm
Width	12.93mm
Contact Finish Thickness	30.0μin 0.76μm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1-745496-9 Product Details

1-745496-9 Overview

A Plug, Male Pins package is included with it.A Free Hanging (In-Line) mounting type is specified for the device.A Bulk case is used for packaging.The product belongs to the AMPLIMITE HDE-20 Series.Packaging with Metal contains a device.It has 1 ports for managing stuff.Its Grounding Indents feature renders it more powerful in many ways.By Cable, Free Hanging it's mounted.A chip with 25 terminations can be found.This device runs at -55°C~105°C operating temperature.
