Name: 1-480699-8
Brand: TE Connectivity AMP Connectors
SKU: 1-480699-8
Price: 0.43000 USD
Availability: InStock

new-10%

1-480699-8

Manufacturer part number:1-480699-8

Manufacturer:TE Connectivity AMP Connectors

Description:1 Rows Receptacle Bulk Gray 2 Positions Panel Mount, Snap-In Male or Female Crimp Universal MATE-N-LOK Nylon

Case Package:SOT-23

Datasheet:1-480699-8 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 4 days ago)
Factory Lead Time	10 Weeks
Mount	Panel
Mounting Type	Panel Mount, Snap-In
Housing Material	Nylon
Packaging	Bulk
Series	Universal MATE-N-LOK
Published	2008
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Receptacle
Number of Positions	2
Max Operating Temperature	125°C
Min Operating Temperature	-55°C
Color	Gray
Number of Rows	1
Voltage - Rated	600V
HTS Code	8536.69.40.30
Fastening Type	Locking Ramp
Contact Type	Male or Female
Pitch	6.35mm
Orientation	Straight
Depth	13.46mm
Current Rating	19A
Approval Agency	CSA
Contact Gender	Female
Housing Color	Grey
Operating Supply Voltage	600V
Note	Contacts Not Included
ELV	Compliant
Max Voltage Rating (AC)	600V
Sealable	No
Contact Termination	Crimp
Contact Retention	Without
VDE Tested	Yes
Length	23.25mm
Panel Thickness	2.29mm
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-2

1-480699-8 Product Details

1-480699-8 Overview

The product comes in a package of Receptacle.Panel Mount, Snap-In is the type of mounting for the device.To package the product, a Bulk case is used.The product is a member of the Universal MATE-N-LOK Series.It is mounted by Panel.Its operating supply voltage is 600V.
