Name: 1-1746237-3
Brand: TE Connectivity AMP Connectors
SKU: 1-1746237-3
Availability: InStock

new-10%

1-1746237-3

Manufacturer part number:1-1746237-3

Manufacturer:TE Connectivity AMP Connectors

Description:1-1746237-3 datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:1-1746237-3 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	18 Weeks
Contact Material	Copper Alloy
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Housing Material	Thermoplastic
Operating Temperature	-25°C~85°C
Packaging	Tape & Reel (TR)
Published	2007
Feature	Solder Retention, Zero Insertion Force (ZIF)
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Number of Positions	35
Number of Rows	1
Gender	Receptacle
Voltage - Rated	50V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	0.2A
Pitch	0.012 0.30mm
Total Number of Contacts	35
Orientation	Right Angle
Current Rating	200mA
Contact Finish	Gold
Housing Color	Beige
ELV	Compliant
Flat Flex Type	FPC
Connector/Contact Type	Contacts, Bottom
Cable End Type	Tapered
Locking Feature	Flip Lock
Actuator Color	Black
Contact Location	Bottom
Height Above Board	0.039 1.00mm
FFC, FCB Thickness	0.20mm
Radiation Hardening	No
REACH SVHC	Unknown
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1-1746237-3 Product Details

1-1746237-3 Overview

Its mounting type is Surface Mount, Right Angle.In order to package the product, a Tape & Reel (TR) case is used.This feature renders it more powerful in a number of ways because of its Solder Retention, Zero Insertion Force (ZIF) feature.This part is mounted by Surface Mount. It operates at an operating temperature of -25°C~85°C.
