Name: DRD16E04
Brand: TE Connectivity
SKU: DRD16E04
Price: 4.59000 USD
Availability: InStock

new-10%

DRD16E04

Manufacturer part number:DRD16E04

Manufacturer:TE Connectivity

Description:DRD16E04 datasheet pdf and DIP Switches product details from TE Connectivity stock available on our website

Case Package:SOT-23

Datasheet:DRD16E04 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Plating	Gold Flash/Nickel
Contact Material	Copper Alloy
Mounting Type	Through Hole
Body Material	Polyphenylene Sulfide (PPS)
Number of Terminals	6
Mounting Style	Through Hole
ECCN (US)	EAR99
Actuator Style	Flush Screwdriver
Pole Throw Configuration	SP16T
Switch Configuration	N.O./N.C.
Maximum AC Voltage Rating (V)	20
Maximum DC Voltage Rating (V)	20
Maximum Power Rating (VA)	0.4@20VDC
Dielectric Strength	300VAC
Minimum Insulation Resistance (MOhm)	1000
Maximum Contact Resistance (mOhm)	50
Electrical Life (Cycles)	10000
Coding	Hexadecimal
Actuator Length (mm)	0
Seal	Process
Seal Description	Process
Mounting	Through Hole
Terminal Pitch (mm)	2.54
Total Pitch (mm)	5.08
Row Space (mm)	7.62
Body Orientation	Straight
Minimum Operating Temperature (°C)	-30
Maximum Operating Temperature (°C)	85
Product Depth (mm)	10
Total # of Positions	16
Operating Temp Range	-30C to 85C
Voltage Rating (VDC)	20(V)
Switch Function Configuration	N.O./N.C.
Rad Hardened	No
Maximum Operating Temperature	+85°C
Minimum Operating Temperature	-30°C
Manufacturer	TE Connectivity
Brand	TE Connectivity / P&B
RoHS	Details
Actuator	Flush
Package	Tube
Base Product Number	DRD16
Mfr	TE Connectivity ALCOSWITCH Switches
Product Status	Active
Packaging	Tube
Operating Temperature	-30°C ~ 85°C
Series	DRD
Part Status	Active
ECCN Code	EAR99
Type	Rotary DIP Switch
Number of Positions	16
Subcategory	Switches
Current Rating (Amps)	0.4VA
Pitch	0.100 (2.54mm), Full
Terminal Pitch	2.54 mm
Reach Compliance Code	compliant
Current Rating	400 mA
Contact Finish	Gold
Termination Style	PC Pins
Actuator Type	Rotary Flush
Brand Name	Alcoswitch
Circuit	Hexadecimal
Electrical Life	10,000 Steps
Mechanical Life	10,000 Steps
Switch Type	DIP
Contact Current Rating	20 mA @ 20 V dc
Product Type	DIP Switches
Operating Temperature Range	-30 → +85°C
Washable	Yes
Actuator Level	Flush, Recessed
Contact Configuration	16P
Mounting Angle	Straight
Features	-
Voltage Rating	20VAC/DC
Product Category	DIP Switches / SIP Switches
Voltage Rating (VAC)	20(V)
Product Length (mm)	10
Length	0.394 (10.00mm)
Height Above Board	0.256 (6.50mm)
Product Height (mm)	6.5
RoHS Status	RoHS Compliant
