Name: B32524Q3475M000
Brand: TDK Electronics Inc.
SKU: B32524Q3475M000
Price: 1.21000 USD
Availability: InStock

new-10%

B32524Q3475M000

Manufacturer part number:B32524Q3475M000

Manufacturer:TDK Electronics Inc.

Description:B32524 4.7μF Film Capacitor ±20% Radial PC Pins 250V-DC 160V-AC Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked

Case Package:SOT-23

Datasheet:B32524Q3475M000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Mounting Type	Through Hole
Package / Case	Radial
Surface Mount	NO
Terminal Shape	WIRE
Dielectric Material	Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked
Operating Temperature	-55°C~125°C
Packaging	Bulk
Series	B32524
Size / Dimension	1.240Lx0.433W 31.50mmx11.00mm
Tolerance	±20%
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	PC Pins
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Applications	Automotive; EMI, RFI Suppression
HTS Code	8532.25.00.70
Capacitance	4.7μF
Voltage - Rated DC	250V
Terminal Pitch	27.5mm
Reach Compliance Code	not_compliant
Reference Standard	AEC-Q200
Voltage - Rated AC	160V
Capacitor Type	FILM CAPACITOR
Lead Spacing	1.083 27.50mm
Rated (DC) Voltage (URdc)	250V
Rated (AC) Voltage (URac)	160V
Custom Capabilities	Special Lead Length Available On Request
Height Seated (Max)	0.827 21.00mm
Length	31.5mm
Width	11mm
RoHS Status	ROHS3 Compliant

B32524Q3475M000 Product Details

B32524Q3475M000 Overview

It is essential that systems function with a rated (DC) voltage (URdc) of 250V.Lead spacing is 1.083 27.50mm for this electrical device.To power systems, URac must be set at 160V V.Devices with a -55°C~125°C temperature capability can be operated.
