Name: B32522C0335K189
Brand: TDK Electronics Inc.
SKU: B32522C0335K189
Price: 0.65000 USD
Availability: InStock

new-10%

B32522C0335K189

Manufacturer part number:B32522C0335K189

Manufacturer:TDK Electronics Inc.

Description:B32522 3.3μF Film Capacitor ±10% Radial PC Pins 63V-DC 40V-AC Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked

Case Package:SOT-23

Datasheet:B32522C0335K189 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	Radial
Surface Mount	NO
Terminal Shape	WIRE
Dielectric Material	Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked
Operating Temperature	-55°C~125°C
Packaging	Tape & Reel (TR)
Series	B32522
Size / Dimension	0.709Lx0.236W 18.00mmx6.00mm
Tolerance	±10%
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	PC Pins
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Applications	Automotive; EMI, RFI Suppression
HTS Code	8532.25.00.70
Capacitance	3.3μF
Voltage - Rated DC	63V
Packing Method	TR
Terminal Pitch	15mm
Reference Standard	AEC-Q200
Voltage - Rated AC	40V
Capacitor Type	FILM CAPACITOR
Lead Spacing	0.591 15.00mm
Rated (DC) Voltage (URdc)	63V
Rated (AC) Voltage (URac)	40V
Custom Capabilities	Special Lead Length Available On Request
Height Seated (Max)	0.433 11.00mm
Length	18mm
Width	6mm
RoHS Status	ROHS3 Compliant

B32522C0335K189 Product Details

B32522C0335K189 Overview

In order for systems to function, a rated (DC) voltage (URdc) of 63V is required internally.Lead spacing is 0.591 15.00mm for this electrical device.Systems require a voltage of 40V (URac) for internal rated (AC) power.It is capable of operating at -55°C~125°C degrees Celsius.
