A7F

A7F

A7F

Switchcraft Inc.

Plug, Female Sockets Stainless Steel Free Hanging (In-Line) 7 Positions Solder Cup Silver Bulk Keyed Latch Lock

SOT-23

A7F Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 12 Weeks
Contact MaterialBrass
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Insulation Material Plastic
Shell Material Stainless Steel
Insert Material Polyester
Backshell Material, Plating Zinc, Nickel
PackagingBulk
Series Q-G® A
JESD-609 Code e4
Feature Backshell, Cable Clamp, Ground, Strain Relief
Part StatusActive
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder Cup
Connector Type Plug, Female Sockets
Number of Positions 7
Applications Audio, Instrumentation
Gender Female
Voltage - Rated 125VAC
Additional FeaturePOLARIZING
Fastening TypeLatch Lock
Contact Finish - Mating Silver
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Keyed
Current Rating5A
Shell Size - Insert XLR
Plating Nickel
Number of Ports1
Number of Poles 7
Cable Opening 0.210 ~ 0.300 (5.33mm ~ 7.62mm)
Length 82.55mm
RoHS StatusROHS3 Compliant
Lead Free Lead Free
In-Stock:228 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$23.070792$23.070792
10$21.764898$217.64898
100$20.532922$2053.2922
500$19.370681$9685.3405
1000$18.274228$18274.228

A7F Product Details

A7F Overview


This product is packaged in a Plug, Female Sockets box.Free Hanging (In-Line) indicates that the device is mounted.An Bulk case is utilized for packaging the product.The product is a part of the Q-G® A Series.Furthermore, there are other features such as POLARIZING, to name a few.In many ways, Backshell, Cable Clamp, Ground, Strain Relief makes it more powerful.By Cable, Free Hanging, the part is mounted.

A7F Features


Q-G® A series


A7F Applications


There are a lot of Switchcraft Inc.
A7F Circular Connectors applications.


  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
  • Control panels
