Name: STTH60R04W
Brand: STMicroelectronics
SKU: STTH60R04W
Price: 6.07000 USD
Availability: InStock

new-10%

STTH60R04W

Manufacturer part number:STTH60R04W

Manufacturer:STMicroelectronics

Description:STTH60R04W datasheet pdf and Diodes - Rectifiers - Single product details from STMicroelectronics stock available on our website

Case Package:SOT-23

Datasheet:STTH60R04W Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Lifecycle Status	ACTIVE (Last Updated: 7 months ago)
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	DO-247-2 (Straight Leads)
Number of Pins	2
Diode Element Material	SILICON
Packaging	Tube
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	175°C
Min Operating Temperature	-40°C
Additional Feature	FREE WHEELING DIODE, SOFT FACTOR IS 0.4
HTS Code	8541.10.00.80
Subcategory	Rectifier Diodes
Base Part Number	STTH60
Pin Count	2
Number of Elements	1
Element Configuration	Single
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Standard
Current - Reverse Leakage @ Vr	60μA @ 400V
Voltage - Forward (Vf) (Max) @ If	1.5V @ 60A
Forward Current	60A
Operating Temperature - Junction	-40°C~175°C
Max Surge Current	650A
Application	ULTRA FAST RECOVERY
Forward Voltage	1.5V
Max Reverse Voltage (DC)	400V
Average Rectified Current	60A
Number of Phases	1
Reverse Recovery Time	80 ns
Peak Reverse Current	60μA
Max Repetitive Reverse Voltage (Vrrm)	400V
Peak Non-Repetitive Surge Current	650A
Reverse Voltage	400V
Recovery Time	80 ns
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

STTH60R04W Product Details

STTH60R04W Overview

There is no reason to reverse the voltage at 400V.Devices like this have an average rectified current of 60A volts.A forward current of 60A is allowed.There can be no surge current above 650A.The datasheets show a peak reverse of 60μA, as shown in the data chart.
