Name: STR912FAW42X6
Brand: STMicroelectronics
SKU: STR912FAW42X6
Availability: InStock

new-10%

STR912FAW42X6

Manufacturer part number:STR912FAW42X6

Manufacturer:STMicroelectronics

Description:256KB 256K x 8 FLASH ARM9® 32-Bit Microcontroller STR9 Series STR912 128 Pin 96MHz 1.8V 128-LQFP

Case Package:SOT-23

Datasheet:STR912FAW42X6 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	128-LQFP
Number of Pins	128
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	STR9
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	128
Terminal Finish	Matte Tin (Sn) - annealed
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	250
Supply Voltage	1.8V
Frequency	96MHz
Base Part Number	STR912
Pin Count	128
Supply Voltage-Max (Vsup)	2V
Interface	CAN, EBI/EMI, Ethernet, I2C, IrDA, SPI, SSP, UART, USART, USB
Memory Size	256kB
Oscillator Type	Internal
Number of I/O	80
RAM Size	96K x 8
Voltage - Supply (Vcc/Vdd)	1.65V~2V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM9®
Peripherals	Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	256KB 256K x 8
Connectivity	CANbus, EBI/EMI, Ethernet, I2C, IrDA, Microwire, SPI, SSI, SSP, UART/USART, USB
Bit Size	32
Data Converter	A/D 8x10b
Has ADC	YES
DMA Channels	YES
Data Bus Width	16b
Core Architecture	ARM
Number of UART Channels	3
Number of ADC Channels	8
Number of PWM Channels	4
Number of I2C Channels	2
Number of Ethernet Channels	1
Height	1.45mm
Length	14mm
Width	14.2mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

STR912FAW42X6 Product Details

STR912FAW42X6 Overview
