Name: STP3NK100Z
Brand: STMicroelectronics
SKU: STP3NK100Z
Availability: InStock

new-10%

STP3NK100Z

Manufacturer part number:STP3NK100Z

Manufacturer:STMicroelectronics

Description:STP3NK100Z datasheet pdf and Transistors - FETs, MOSFETs - Single product details from STMicroelectronics stock available on our website

Case Package:SOT-23

Datasheet:STP3NK100Z Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	TO-220-3
Number of Pins	3
Transistor Element Material	SILICON
Operating Temperature	-55°C~150°C TJ
Packaging	Tube
Series	SuperMESH™
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
Terminal Finish	Tin (Sn)
Subcategory	FET General Purpose Power
Technology	MOSFET (Metal Oxide)
Base Part Number	STP3N
Pin Count	3
Number of Elements	1
Power Dissipation-Max	90W Tc
Element Configuration	Single
Operating Mode	ENHANCEMENT MODE
Power Dissipation	90W
Turn On Delay Time	15 ns
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	6 Ω @ 1.25A, 10V
Vgs(th) (Max) @ Id	4.5V @ 50μA
Input Capacitance (Ciss) (Max) @ Vds	601pF @ 25V
Current - Continuous Drain (Id) @ 25°C	2.5A Tc
Gate Charge (Qg) (Max) @ Vgs	18nC @ 10V
Rise Time	7.5ns
Drain to Source Voltage (Vdss)	1000V
Drive Voltage (Max Rds On,Min Rds On)	10V
Vgs (Max)	±30V
Fall Time (Typ)	32 ns
Turn-Off Delay Time	39 ns
Continuous Drain Current (ID)	12.5A
Threshold Voltage	3.75V
JEDEC-95 Code	TO-220AB
Gate to Source Voltage (Vgs)	30V
Drain-source On Resistance-Max	6Ohm
Drain to Source Breakdown Voltage	1kV
Height	15.75mm
Length	10.4mm
Width	4.6mm
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

STP3NK100Z Product Details

STP3NK100Z Description

STP3NK100Z is a 1000v N-channel SuperMESH? Power MOSFET. The high-voltage device STP3NK100Z is a Zener-protected N-channel Power MOSFET developed using the SuperMESH? technology by STMicroelectronics, an optimization of the well-established PowerMESH?. In addition to a significant

reduction in on-resistance, the STP3NK100Z is designed to ensure a high level of dv/dt capability for the most demanding applications.
