Name: L4978D
Brand: STMicroelectronics
SKU: L4978D
Availability: InStock

Technical Specifications

Parameter Name	Value
Type	Parameter
Factory Lead Time	25 Weeks
Lifecycle Status	ACTIVE (Last Updated: 7 months ago)
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	16-SOIC (0.295, 7.50mm Width)
Number of Pins	16
Operating Temperature	-40°C~150°C TJ
Packaging	Tube
JESD-609 Code	e4
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	16
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory	Switching Regulator or Controllers
Technology	BCDMOS
Terminal Position	DUAL
Terminal Form	GULL WING
Frequency	300kHz
Base Part Number	L4978
Function	Step-Down
Number of Outputs	1
Efficiency	87 %
Voltage - Input (Max)	55V
Output Voltage	50V
Output Type	Adjustable
Max Output Current	2A
Operating Supply Voltage	55V
Voltage - Input (Min)	8V
Input Voltage-Nom	24V
Analog IC - Other Type	SWITCHING REGULATOR
Output Configuration	Positive
Max Output Voltage	50V
Topology	Buck
Control Mode	VOLTAGE-MODE
Frequency - Switching	100kHz~300kHz
Control Technique	PULSE WIDTH MODULATION
Supply Current-Max (Isup)	6mA
Synchronous Rectifier	No
Dropout Voltage	580mV
Min Output Voltage	3.3V
Height	2.35mm
Length	10.5mm
Width	7.6mm
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

L4978D Product Details

L4978D Overview

As a result of the use of the Tube package, the performance of this voltage regulator is optimized. As you can see, this harley voltage regulator contains 16 terminations. There are two types of analog ICs on this voltage regulator. The first type is a SWITCHING REGULATOR-type IC. Space-saving 16-SOIC (0.295, 7.50mm Width) packages are available for this harley voltage regulator. There are 1 outputs configured on the voltage regulator. ICs such as this voltage regulator are capable of generating Adjustable outputs through their output pins. The voltage regulator 12v fits the Surface Mount mounting hole. This voltage regulator 12v should operate at a temperature of -40°C~150°C TJ when operating. 100kHz~300kHz is the switching frequency of this DC-DC switching regulator. A dc to dc voltage regulator's minimum input voltage of 8V is required for this voltage regulator to operate. The maximum input voltage of voltage regulator is 55V. To meet the switching regulator operation requirements, a nominal input voltage of 24V is provided. I would like to point out that this voltage regulator belongs to the Switching Regulator or Controllers subcategory. DC/DC regulators such as this one belong to the L4978 family of products. Voltage of voltage regulator can be delivered at 50V volts. In order to operate voltage regulator, there are 16 pins that must be connected. For this switching regulator, it is recommended that the output voltage is at least 3.3V volts. In order to meet the requirements of the switching regulator operation, the maximum output current reaches 2A A. As a result, it is able to provide adjusting voltage regulator a maximum output voltage of 50V. DC-DC switching regulator with 55V supply voltage. At a frequency of 300kHz, dc to dc voltage regulator is capable of maintaining high accuracy.
