L4936EH Overview
In a Tube case, the IC voltage regulator is delivered. A Multiwatt-15 (Vertical, Bent and Staggered Leads) case contains the Liner IC. In total, there are 15 terminations on the gadget. This PMIC chip has an output type of Adjustable (Fixed). In this electrical part, there are 2 regulators that are implemented. Voltage Regulated IC Through Hole varies its operating temperature range. The IC Voltage Regulator's operating temperature is -40°C~150°C degrees. Currently, this regulator IC has an output function configured as Positive as its output function. The current output of this IC regulator is 100mA 400mA. There are 15 pins in total on this board. Featuring 2 outputs in total, this voltage regulator IC enables prompt, sufficient performance regardless of the application. There is a 10 volt dropout voltage on this transistor. A 15-pin is present on the chip. It is L4936 for this voltage regulator IC, just for your information. It operates in the 20mA Quiescent Current state.
L4936EH Features
200mV dropout voltage
L4936EH Applications
There are a lot of STMicroelectronics
L4936EH Linear Voltage Regulators applications.
- Portable telephone
- Electronic notebook
- Camera
- Video equipment
- CPU power supply
- Switching regulator
- Multiple-power supply system
- Digital audio player
- Digital TV
- Smartcard
