Name: UTS014D5S
Brand: SOURIAU-SUNBANK
SKU: UTS014D5S
Price: 23.34000 USD
Availability: InStock

new

UTS014D5S

Manufacturer part number:UTS014D5S

Manufacturer:SOURIAU-SUNBANK

Description:Receptacle, Female SocketsPolybutylene Terephthalate (PBT)Panel Mount, Through Hole5 PositionsSolderGoldBulkN (Normal)Bayonet Lock

Case Package:SOT-23

Datasheet:UTS014D5S Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Contact Material	Brass
Mount	Flanges, Panel, Through Hole
Mounting Type	Panel Mount, Through Hole
Mounting Feature	Flange
Shell Material	Polybutylene Terephthalate (PBT)
Insert Material	Polychloroprene
Operating Temperature	-40°C~105°C
Packaging	Bulk
Series	Trim Trio® UTS Hi Seal
Feature	UV Resistant
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Receptacle, Female Sockets
Number of Positions	5
Color	Black
Applications	Energy, Instrumentation, Lighting, Telecommunications
Voltage - Rated	600V
Fastening Type	Bayonet Lock
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Total Number of Contacts	5
Orientation	N (Normal)
Shielding	Unshielded
Ingress Protection	IP68/69K - Dust Tight, Water Resistant, Waterproof
Current Rating	12A
Shell Size - Insert	14-5
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Contact Gender	Female
Empty Shell	NO
Backshell Type	SOLID
Environmental Characteristics	CORROSION/MOISTURE RESISTANT
Contact Finish Thickness - Mating	16.0μin 0.41μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant
Ratings	Dust Tight, IP68, Waterproof

UTS014D5S Product Details

UTS014D5S Overview

It comes in a Receptacle, Female Sockets package.There is a mounting type of Panel Mount, Through Hole for this device.It is necessary to use a Bulk case for packaging the product.It belongs to the Trim Trio® UTS Hi Seal Series of products.It is more powerful in many ways due to its UV Resistant feature.This part is mounted by Flanges, Panel, Through Hole. In this case, the device operates at -40°C~105°C Operating Temperature.
