MS27484T8B98S-LC

Name: MS27484T8B98S-LC
Brand: SOURIAU
SKU: MS27484T8B98S-LC
Price: 78.16000 USD
Availability: InStock

new

Manufacturer part number:MS27484T8B98S-LC

Manufacturer:SOURIAU

Description:Aluminum

Case Package:SOT-23

Datasheet:MS27484T8B98S-LC Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Copper Alloy
Contact Plating	Gold Over Nickel
Shell Material	Aluminum
Number of Terminals	3
Mounting Style	Cable
ECCN (US)	EAR99
Military Standard Series	Series II
AEC Qualified	No
Mounting	Cable Mount
Body Orientation	Straight
Product Diameter (mm)	19.05
Insulation Resistance (MOhm)	5000
Maximum Contact Resistance (mOhm)	7.3
Mating Style	Bayonet Lock
Mating Cycle (Cycles)	500
Termination Method	Crimp
Shell Size / Insert Arrangement	8-98
Less Contact	Yes
Maximum Current Rating (A)	7.5
Minimum Operating Temperature (°C)	-65
Maximum Operating Temperature (°C)	175
Product Depth (mm)	Not Required(mm)
Operating Temp Range	-65C to 175C
Rad Hardened	No
Contact Classification	3Signal
Part Status	Active
Type	Circular
Gender	PL
Military Standard	MIL-C-38999
Number of Contacts	3
Contact Gender	SKT
Housing Color	Olive Drab
Polarization	N
Number of Ports	1
Family	MS27484
Wire Size (AWG)	20-24
Current Rating (Max)	7.5(A)
Shell Plating	Cadmium
Strain Relief	No
Product Length (mm)	23.27
Product Height (mm)	Not Required(mm)
RoHS Status	RoHS non-compliant
